VPN on a Keenetic router: AmneziaWG or WireGuard, a file from your account, 10 minutes

A VPN on a Keenetic router installs with no reflashing and no command line: KeeneticOS understands AmneziaWG "out of the box", and the file from your account uploads straight into the router's web interface. The whole thing takes about ten minutes. After that, every device at home goes through the VPN at once — the TV, a streaming box, guests' phones — and for NvoVPN the router counts as one device. If you are in Russia, take the AmneziaWG file; details in the block below.

1. 1

   Download the file from your account

   Open your account → "Connection" → "Manual". Choose a server, name the device "Router" and click "Create". Download the .conf file for AmneziaWG. Next to it is a plain WireGuard variant — on a Keenetic with KeeneticOS 4.3.4 or later, you do not need it. The file is only created while a plan or trial is active.

2. 2

   Check KeeneticOS and the WireGuard component

   The file from your account is AmneziaWG version 1.0; KeeneticOS has been able to read it from a file since version 4.3.4, so KeeneticOS 5.1 is not required. In the router's web interface, open "Management" → "System settings": update KeeneticOS to the current version, then click "Change component set", find "WireGuard VPN" and tick it. There is no separate "AmneziaWG" entry in the list — it is part of this component.

3. 3

   Upload the file and turn on internet access

   "Internet" → "Other connections" → in the WireGuard section, click "Upload from file" and choose the downloaded .conf. In the connection that opens, tick "Use for internet access", click "Save", and make sure the connection toggle is set to "On". Then open "Internet" → "Connection priorities" and drag WireGuard above the provider's connection — that sends all traffic through the tunnel.

4. 4

   Check that the VPN is working

   From a TV or laptop behind the router, open the "What is my IP" page: it should show the NvoVPN server's address, not your provider's. If you see your own city and provider, see the "If the router will not connect" section below.

If the router will not connect: Keenetic pitfalls

• DNS. Keenetic's WireGuard connection has no DNS field, the DNS = line from the file is not applied, and site-name lookups go to the provider, bypassing the tunnel. Set the DNS separately: "Network rules" → "Internet filters" → the "DNS settings" tab → "Add server" — enter the address from your file's DNS line, or a public one (8.8.8.8, 1.1.1.1). In the same place, under "IPv4 parameters", tick "Ignore the ISP's DNSv4".
• The tunnel is up, but there is no internet. Check the "Use for internet access" tickbox and the order in "Connection priorities": the connection with the highest priority becomes the default gateway, and WireGuard needs to be above the provider.
• An "invalid H1 value" error when uploading the file. The firmware does not understand the obfuscation parameters in the file. Update KeeneticOS to the current version and upload the file again.
• The connection keeps dropping. Keenetic recommends a client Persistent keepalive interval of 10–15 seconds instead of the standard 30 — the value is set in the peer settings inside the connection.
• One file, one device. You cannot use the router's configuration on a phone at the same time: the connection will drop on both. Create a separate one for the phone — a subscription covers up to five.
• Only some devices need the VPN. "Internet" → "Connection priorities" → "Add policy" → name it → "Save" → in the policy, mark WireGuard first → "Save" → the "Policy assignment" tab → drag devices or network segments into the policy → "Confirm". Up to 16 policies.
• A kill switch (blocking internet access if the tunnel drops) is not in every router's firmware. If this matters to you, check for the option in your model's VPN client settings, or turn it on on the devices themselves — how to do that.

Keenetic models and firmware

Per the manufacturer's data as of September 2026; the current release is KeeneticOS 5.1.6 from September 16, 2026. Before buying, check your model on its Keenetic downloads page.

• KeeneticOS 5.1 (the current branch) goes to Giga (KN-1010), Hero (KN-1011, KN-1012), Ultra and Titan (KN-1810–1812), Viva and Skipper (KN-1910, KN-1912, KN-1913), Starter (KN-1112, KN-1121), Air and Explorer (KN-1613, KN-1621), Extra and Carrier (KN-1713, KN-1714, KN-1721), Speedster, Hopper, Sprinter, Challenger, Racer, Peak, Giant, Buddy, Voyager Pro, Orbiter, and the 4G and DSL models (except Runner 4G KN-2210). The NvoVPN file uploads from a file.
• Stopped at KeeneticOS 4.3: Start (KN-1110, KN-1111), Omni (KN-1410), City (KN-1510), Air (KN-1610), Extra (KN-1710, KN-1711), Runner 4G (KN-2210), Speedster (KN-3010). Update these to 4.3.4 or later — they also load the NvoVPN file (AmneziaWG 1.0) from a file. AmneziaWG 1.5 and 2.0 files from other services (with S3, S4, I1 parameters) do not work on them.
• Lite (KN-1310) stopped at KeeneticOS 4.2: the obfuscation parameters are entered manually through "Management" → "System settings" → "Command line", following the Amnezia guide for older KeeneticOS versions, or you take the WireGuard variant — where VPNs are not throttled.
• Netcraze runs on the same KeeneticOS — the steps are the same.
• AmneziaWG 3.1 is not natively supported by KeeneticOS. This does not affect the NvoVPN file: it is version 1.0.

Official WireGuard throughput from the model pages on keenetic.com:

FAQ

Do I need KeeneticOS 5.1 for AmneziaWG? Not for the NvoVPN file — it is version 1.0, and KeeneticOS has read it from a file since 4.3.4. Version 5.1 is needed for AmneziaWG 1.5 and 2.0 files with S3, S4 and I1 parameters — on KeeneticOS 5.0.8 and earlier, those files produce an "invalid H1 value" error.

Can I route only the TV through the VPN? Yes — create a policy in "Connection priorities" and drag the TV into it on the "Policy assignment" tab (steps are in the pitfalls section above). The other devices will keep going out directly.

Why is the speed through the router lower than my plan? The router's CPU computes the encryption, and it becomes the bottleneck: entry-level Keenetic models officially give up to 45 Mbps through WireGuard, the higher-end ones hundreds. Even the entry-level models are enough for a TV and everyday use.

Can I put the same file on a phone? No — one file only works on one device at a time. Create a separate configuration for the phone in your account, or install the NvoVPN app: a subscription covers up to five devices, and the router is one of them.

Can I skip updating KeeneticOS? On KeeneticOS 4.2–4.3.3, the file uploads without the obfuscation parameters — they are entered manually through "Command line" following the Amnezia guide (linked in the models section). It is simpler and more reliable to update the firmware: from 4.3.4 on, everything comes from the file.
